Hisense Digital Signage Displays
For Public, Retail And Business Locations
M Series 49” & 55” Digital Signage Displays
49” & 55” 4K UHD Digital Signage Display
Hisense’s BM66AE Digital Signage Displays (49”/55”) are perfectly fit for public transport and retail locations. Their slim body design will make them blend into their surrounding and make your on-screen messaging stand out. Their vivid and vibrant colours immerse viewers and will effectively provide them with the information they are looking for.
All this with the flexibility and reliability that are required for round-the-clock broadcasting locations due to light sensors, intelligent temperature control and dual-core SOC technology for PC-less offline or cloud based content management. You can rest assure your content will be delivered 24/7 in an elegant, vibrant and reliable way.
Round-the-clock operation
Designed with dual-core System on Chip (SoC) technology the Hisense BM66AE series can be used as reliable digital signage displays for both offline and cloud based content. You are completely free to choose your content management system to help display your advertising. And if necessary the internal memory will allow you to upload media into the display for instant broadcast without the need for external hard- or software.
Smart CMS
Hisense’s CMS platform allows you to edit and arrange playlists, making content management easy and user-friendly. It supports all rich media content in synchronous playback over a multitude of commercial displays. Besides this status monitoring and real-time control will allow you to quickly and centrally respond to any emergency.
178° Wide viewing angle
The extra wide 178° viewing angle is a perfect fit for shoppers, employees or visitors that will view displays from diverse angles while passing by.
Landscape & portrait
Both landscape and portrait orientations are possible, providing you with endless creative and functional possibilities to fulfil your commercial or informative goals.
500 nits
With 500 nits maximum brightness the display panels can deliver amazingly vivid imagery anywhere during daytime and nighttime conditions
4K Ultra HD
The 4K Ultra HD picture quality* ensures perfect colour and rich details in all possible broadcasting surroundings, ranging from shops, to restaurants and office buildings.
Automatic time zone
When connected to the Internet each display will automatically synchronise to its local timezone. Making sure scheduled media broadcast is always in sync
Customisation
Hisense’s displays support a variety of on-screen customisations such as custom startup logo, startup animation, wallpaper and many more. Creating a uniform look & feel for all people working with or viewing the displays
Auto brightness
Thanks to our advanced auto brightness sensor the BM66AE displays will intelligently adjust their brightness to their surroundings. Making sure energy usage is optimised at all times.
Slim design
With 12mm bezels the BM66AE displays are the slimmest and most elegant in our range. Making sure your broadcasting content is always the focus of attention.
Dust & humidity protection
The main board and power board of each Hisense BM66AE display is coated so it will effectively resist the erosion by dust and water vapour in public space conditions.
Temperature protection
The BM66AE displays are resistant to high temperatures and have an automatic temperature control mechanism. They will automatically adjust their backlight brightness when their temperature reaches 75°C to cool the display. At 100°C they will automatically switch to standby mode.
Fail over
Stable broadcast is ensured with fail over functionality. When the primary source of content goes down the system will automatically switch to predetermined alternative input. All input sources (HDMI,DVI,VGA,DP) also support auto detect functionality.
Detachable logo
For customisation needs the Hisense logo has been made detachable. If for instance you want to arrange multiple BM66AE displays to form a video wall the logos can be freely removed.
49” Specifications
Panel
Backlight: ELED
Size: 49’’
Resolution: 3840 x 2160
Refresh rate: 60HZ
Brightness: 500 nits (typ)
Contrast(typ): 1100:1 (typ)
Orientation: Landscape & Portrait
MTBF: 50000hrs
Operation Hours: 7Day*24Hour
Control Method
Remote: IR
RS232: RS232*1 (RJ45)
Speaker
Built in speaker: 8W x2
Power
Input: AC 100V-240V@50-60HZ
Power Consumption: 100W(Max)
Standby Consumption: <0.5W
Environment
Operation Temperaturer: 0 - 40°
Operation Humidity: 10% - 80%
Connectivity
WIFI: 2.4G/5G
LAN: 10/100Mbps
Operating System
OS: Android 7.0
Physical
Bezel Color: Black
Set Dimension(WxHxD):1105×639×64.3mm
Bezel width (T/L/R/B): 11.9mm(T),15.4mm(B),12.4mm(L/R)
Net Weight: 20.5kg
Packing Dimension(WxHxD): 1208×199×748mm
Packed Weight: 17kg
VESA: 300*300mm
Certification
Standard Certification: CB,CE,ERP
What’s in the box
User manual
Remote controller
Power cord
Logo accessory
55” Specifications
Panel
Backlight: ELED
Size: 55’’
Resolution: 3840 x 2160
Refresh rate: 60HZ
Brightness: 500 nits (typ)
Contrast(typ): 1100:1 (typ)
Orientation: Landscape & Portrait
MTBF: 50000hrs
Operation Hours: 7Day*124Hour
Control Method
Remote: IR
RS232: RS232*1 (RJ45)
Speaker
Built in speaker: 8W x2
Power
Input: AC 100V-240V@50-60HZ
Power Consumption: 120W(Max)
Standby Consumption: <0.5W
Environment
Operation Temperaturer: 0 - 40°
Operation Humidity: 10% - 80%
Connectivity
WIFI: 2.4G/5G
LAN: 10/100Mbps
Operating System
OS: Android 7.0
Physical
Bezel Color: Black
Set Dimension(WxHxD):1241×714.5×66mm
Bezel width (T/L/R/B): 11.7mm(T),14.8mm(B),12.2mm(L/R)
Net Weight: 20.5kg
Packing Dimension(WxHxD): 1374×143×847mm
Packed Weight: 20.5kg
VESA: 300*300mm
Certification
Standard Certification: CB,CE,ERP
What’s in the box
User manual
Remote controller
Power cord
Logo accessory
Hisense E3 SERIES 43”/55”/65”/75”/86”
FOR BROADCASTING DURING ‘OPENING HOURS’
Hisense’s E3 Series Digital Signage Displays (B4E31T 43”/55”/65” & B4E30T 75”/86”) are ideal for public spaces, retail locations and business environments. They form an integrated entry-level broadcasting platform for digital content in supermarkets, restaurants, shopping malls, office buildings and public spaces such as trainstations. Their even bezel design will make the panels blend completely into their surrounding, but their radiant 500 nits brightness will make your commercial content vividly stand out. Resulting in more effective information sharing, striking inspiration and higher sales.
The smart Hisense CMS platform will make content management easy and user-friendly. If required or desired you are completely free to connect any alternative third party CMS and real-time control will allow you to centrally monitor and manage all your digital displays. All this with the reliability you expect for heavy commercial areas with increasingly extended opening hours. You can rest assured your content will be delivered 16 hours a day and 7 days a week in an affordable, smart and reliable way.
ANY SIZE DISPLAY
FOR ANY SIZE PUBLIC, RETAIL OR OFFICE SPACE
Landscape & portrait
Both landscape and portrait orientations are possible, providing you with endless creative and functional possibilities to fulfill your commercial or informative goals.
4K Ultra HD
The 4K Ultra HD picture quality ensures perfect colour and rich details in all possible broadcasting surroundings, ranging from shops, to restaurants and office buildings.
178° Wide viewing angle
The extra wide 178° viewing angle is a perfect fit for shoppers, employees or visitors that will view E3 displays from diverse angles while passing by.
HDMI detection
Stable broadcast is ensured with fail detection functionality. When one HDMI source of content goes down the system will automatically switch to another HDMI source.
Opening hours’ operation
Hisense’s industrial grade IPS commercial panels are designed with reliable quad-core System on Chip (SoC) technology. Because of this the Hisense E3 Series can be used for stable broadcasting both offline and cloud based content 16 hours a day, 7 days a week.
Even Bezel
All E3 Series displays are Even Bezel designed leading to seamless single- or multi-display images and video, without any distortions. True to form content will provide an even more immersive viewer experience.
500 nits
With 500 nits maximum brightness the display panels are well equipped to make your content vividly stand out in any dimly lit or ultra bright environment.
SoC Specifications 43”/55”/65”/75”/86”
CPU: A73*2+A53*2 Up to 1.5GHz
GPU: 4+2 Up to 600MHz
Memory Support: 2G+16G (43”/55”/65”) & 3G + 16G (75”/86”)
OS: Android 8.0
USB Support: USB2.0/USB3.0
UHD Support: YE
